GrowSpan 2000 Series - End Frame Solid (G)

9
Revision date: 12.06.19 GK2EW24120B_G
End Frame Solid (G)
ATTENTION: See End Frame Connections
Details 1-4 showing how to anchor vertical
end wall columns in concrete.
4'-2"
8'-10" 4'-2"
4'-0"
4'-0"
1'-5"
2'-7"
3'-5"
3'-5"
5/8"
2'-0"
EMBEDMENT
B
T
T
C1
TOP OF POST
GROUND LEVE
L
GT
GT
T
GT
C2
C1
C2
GT
GT
GT
GT
GT
GT
T
GT
B
NOTES:
ALL DIMENSIONS ARE FROM CENTER TO CENTER UNLESS
OTHERWISE NOTED.
GIRTS/FRAMING CHANNEL MAY REQUIRE FIELD CUTTING TO FIT.
ENDWALL COLUMNS:
C1
PG2X2EC14L16200
(2" x 2" 14 GA 1-PLY SQUARE TUBE)
GIRT/DOOR FRAME
GT 111635
(14 GA PROFILE)
T
PGBRKAAS01
(CONNECTION PLATE)
COLUMN TOP CONNECTION PLATE:
112357
(GROUND POST INSERT)
B
COLUMN BOTTOM GROUND POST INSERT:
PG2X2EC14L18750
(2" x 2" 14 GA 1-PLY SQUARE TUBE)
C2
LATERAL BRACING BRACKET:
LB
QH1070
(PIPE STRAP)
GRT2X2G16L144 (16 GA PROFILE)
