Grundig CMS 5000 BT DAB+ WEB - Technical Specifications: Display and Network; Display and Network Specs; Technical Specifications: Radio and Audio; Radio and Audio Specs

35
ENGLISH
SAFETY AND INFORMATION
-----------------------------------------------------------------------
Model number CMS 5000 BT DAB+ WEB
Display 2.4", 320 x 240, TFT colour display
Network supported
WiFi IEEE 802.11a/b/g/n wireless;
Bluetooth
WiFi : 2.412 - 2.472 GHz, 5.18 - 5.32 GHz, 5.50 - 5.70GHz,
5.745 – 5.825GHz; Bluetooth: 2.402 - 2.48 GHz
(BT 4.2, Supports A2DP, AVRCP profiles)
Frequency band
Radio frequency
power transmitted
WiFi 2.4G: 17.6dBm; WiFi 5G: 16.38dBm; WiFi 5.8G:
8.07dBm; Bluetooth: 7.59dBm
Encrypted key WEP, WPA, WPA2 (PSK), WPS
Streaming Supported
Formats
MP3, AAC/AAC+ (up to 48kHz, 16bits)
USB Supported Formats MP3, WMA, AAC, FLAC (sampling rate MAX: 48kHz)
CD Supported Formats
CD(12cm), CD-R, CD-RW, MP3-CD, WMA-CD
MP3, WMA (DRM not supported), CD-audio
DAB / DAB+ Band III, 174.928 – 239.200 MHz
FM 87.5 – 108.0 MHz
USB Charging Output: DC 5V 1000 mA
USB Playback System compatibility: FAT 16, FAT 32
Battery (Remote Control) 2 x 1.5V AAA
Standby mode power
consumption
<1.0W
Networked standby
power consumption
<2.0W
Operating temperature
0
o
C - 35
o
C
Speaker power output 2 x 50W RMS
Speaker Impedance 6Ω
Signal-to-noise ratio ≥60 dB
Frequency response 20Hz – 20kHz
Audio Connections
3.5mm headphone socket (front)
RCA in jack (back)
Speaker out jack, 6Ω (back)
Dimensions
Main unit: 300mm(L) x 106mm(H) x 234mm(D)
Speakers: 220mm(L) x 330mm(H) x 276mm(D)
100-240V~50/60Hz
Weight
AC Mains
Main unit: 2.3kgs; Speakers: 5.3kgs
