Table 3-1: Parameter Map
Parameter
Number
Display
Name
Default
Value
Valid Range/ Choices
Parameter
Description
Page
P110.--
F.S.=
100.00
.01 – 999,999
(Keyed In)
Full Scale
23
P111.06
1Grad
0.01
.00001 – 500
(24 Selections)
Count By (division size)
23
P112.05
Ztrac
0.5d
Off - 20.0d
(200 Selections)
Zero Track Aperture
23
P114.10
Stabl
1.0d
Off – 20.0d
(200 Selections)
Stability Window
23
P115.10
StDly
1 Sec
0.05 – 10.0 Sec
(101 Selections)
Stability (Motion) Delay
23
P116.04
Filtr
1 Sec
.06 – 8.00 Sec
(8 Selections)
Filter Setting
23
P117.03
Rate=
0.3 Sec
0.05 – 20.0 Sec
(201 Selections)
Display Update
23
P118.12
Zrang
100%
.01 – 100%
(13 Selections)
Zero Button Range
23
P119.00
LinrZ
Disable
Enable / Disable
(Toggle)
Linearization
24
P150.00
Units
lb
lb / kg / other
(Toggle)
Default (Calibration) Units
24
P151.01
Unbut
Enable
Enable / Disable
(Toggle)
Units Button
24
P152.00
Unit3
None
None / ounce / gram / lb oz
(4 Selections)
Additional Unit
24
P161.00
TarSa
Disable
Enable / Disable
(Toggle)
Tare Save
24
P166.01
AutoT
Enable
Enable / Disable
(Toggle)
Auto Tare
24
P167.01
TarIn
Disable (370)
Enable (375)
Enable / Disable
(Toggle)
Keyboard Tare
24
P169.00
AtClr
Disable
Enable / Disable
(Toggle)
Auto Tare Clear
24
P171.00
AnAlg
Disable
Enable / Disable
(Toggle)
Analog Output Option
24
P179.01
Count
Enable
Enable / Disable
(Toggle)
Counting Functions
24
P200.00
Baud1
9600
150 – 115K
(13 Selections)
Comm 1 Baud Rate
24
P201.01
Data1
8 Bits
7 – 8 Bits
(2 Selections)
Comm 1 Data Bits
24
P202.00
Par 1
None
None – Odd
(3 Selections)
Comm 1 Parity
25
P203.00
Stop1
1 Bit
1 – 2 Bits
(2 Selections)
Comm 1 Stop Bits
25
P204.02
HndS1
Soft
None – Both
(4 Selections)
Comm 1 Handshake
25
P210.01
Send1
Press
Off – ID
(5 Selections)
Comm 1 Transmit
25
P212.01
Stbl1
Delay
Off – Delay
(Toggle)
Comm 1 Motion
25
P213.01
Ttyp1
--2--
1 – 16, Custom
(Selection)
Print Transmission
25
P220.00
Baud2
9600
150 – 115K
(13 Selections)
Comm 2 Baud Rate
25
P221.01
Data2
8 Bits
7 – 8 Bits
(2 Selections)
Comm 2 Data Bits
25
P222.00
Par 2
None
None – Odd
(3 Selections)
Comm 2 Parity
25
P223.00
Stop2
1 Bit
1 – 2 Bits
(2 Selections)
Comm 2 Stop Bits
25
P224.02
HndS2
Soft
None – Soft
(2 Selections)
Comm 2 Handshake
25
