GSi 1100 Series Operator's Manual

2. Decals
PNEG-1456 1 and 2 Fan Vision Series Portable Dryers 9
Moving parts can crush
and cut. Keep hands
clear. Do not operate
without guards in place.
Failure to do so could
result in serious injury.
DC-972
WARNING!
DC-974
Rotating auger will crush
and cut. Auto equipment
can start at anytime. Do not
enter until electric power is
locked in off position. Failure
to do so will result in serious
injury or death.
WARNING!
Automatically controlled
belt drive can start at
anytime. Keep hands
clear. Failure to do so
could result in serious
injury.
DC-971
Decal: DC-972
Decal DC-972 is located on the bottom auger belt guard and the front bearing
plate (which is visible when the bottom auger belt guard is removed).
An alternate location would be at the rear of the dryer for portable dryers
equipped with the Front Discharge Option.
Decal: DC-971
Decal DC-971 is located on the bottom auger belt guard and the front bearing plate
(which is visible when the bottom auger belt guard is removed). An alternate location
would be at the rear of the dryer for portable dryers equipped with the
Front
Discharge Option
.
Another location for decal DC-971 is on the top of the auger belt guard (one on the
belt guard cover and one on the inside belt guard body visible when the belt guard
cover is removed).
Decal: DC-974
Decal DC-974 has several different locations. Two (2) are located on the front end
panel below the fan/heater. Two (2) are located on the rear end panel below the rear
access door. Two (2) are located on the auger discharge box (one on the outside top
and one on the inside of the flapper lid next to the discharge mercury switch). One
more of these decals is located inside the plenum on the rear plenum closure door
just inside the rear access door.
