GSi 61 - Page 70

Grason-Stadler GSI
®
61 CLINICAL AUDIOMETER
The configuration is selected as follows:
OFF = Logical 1 ON = Logical 0
Baud rate: Position # 3 2 1 Selection
OFF OFF OFF 9600 Baud (GSI 16 compatible)
OFF OFF ON 4800 (GSI 16 compatible)
OFF ON OFF 2400 (GSI 16 compatible)
OFF ON ON 1200 (GSI 16 compatible)
ON OFF OFF 600 (GSI 16 compatible)
ON OFF ON 19.2K
ON ON OFF Invalid Selection
ON ON ON Invalid Selection
Parity/Data Bits: Position # 5 4 Selection
OFF OFF No Parity /8 Data Bits
OFF ON Odd Parity /7 Data Bits
ON OFF Even Parity /7 Data Bits
(GSI 16 compatible)
ON ON Space Parity /7 Data Bits
Data Flow Control: Position #6 OFF = Hardware flow control used.
(GSI 16 compatible)
ON = Software Flow control used.
Stop Bits: Position #7 OFF = 1 Stop bit
ON = 2 Stop bits (GSI 16 compatible)
Position #8 This position is not used.
The default settings are 9600 baud, no parity, 8 data bits, 1 stop bit, and hardware flow
control.
6-2
1761-0100 Rev. B
