GSi 61 - Page 83

Contains information on the type of error which has occurred. The types of errors which
would result in an Error Record are:
• System errors
• Input record which has an incorrect format or is invalid for the current operating
mode
• Pushbutton operation commands which are invalid
Character Offset Number of Field Name Field Description
Characters
0 1 Record Prefix “:”
1 1 Record Type “4”
2 2 Error Code See next table;
Error Codes
4 2 Checksum See page 6-4; Checksums
6 2 Record Terminator “CR,” “LF”
6-15
Character
Offset
15
16
18
19
23
24
28
29
4
40
42
Number of Field Name
Characters
Tracking
Zero Field
HL Step Size
Ch 1 Numeric
HL Display Data
1
2
1
4
1
4
1
5
6
2
2
Chapter 6 - Remote Options
Field Description
“0” = Off
“1” = On
“00”
“1” = 1 dB
“2” = Reserved for GSI 10
“3” = 5 dB
“4” = 2 dB
“-100” to “1200”
Range: -10.0 to 120.0 dB
Ch 1 Interrupt “0” = Off
“1” = On
Ch 2 Numeric HL “-100” to “1200”
Display Data Range: - 10.0 to 120.0 dB
Ch 2 Interrupt “0” = Off
“1” = On
Frequency Display “__125” to “12000”
Data Range: 125 to 12000 Hz in
standard audiometric frequencies
Zero Field “000000”
Checksum See page 6-4; Checksums
Record Terminato
r
“CR,” “LF”
Output Record
Type 4 - Error
Record
