Chapter 6 - Remote Options
Character Number of Data Type Field Name Field Description
Offset Characters
784
8 Alternate Test - See Alternate Test -
14 kHz 125 Hz fields
792 8 Alternate Test - See Alternate Test -
16 kHz 125 Hz fields
800 8 Alternate Test - See Alternate Test -
18 kHz 125 Hz fields
808 8 Alternate Test - See Alternate Test -
20 kHz 125 Hz fields
816 814 See Left Ear fields
1630 2 uChar Checksum See page 6-4;
Checksums
1632 2 ASCII Record Terminator “CR,” “LF”
Note: HL threshold values are transmitted as hexadecimal values scaled by 2.
Contains the instrument type and software version information. This record is not GSI 16
compatible.
Character Offset Number of Field Name Field Description
Characters
0 1 Record Prefix “:”
1 1 Record Type “7”
2 2 Instrument Type “04”
4 5 Software Revision “xx.xx”
9 2 Checksum See page 6-4; Checksums
11 2 Record Terminator “CR,” “LF”
6-23
Right Ear Test
Data
Record
Terminator
Output Record
Type 7 -
Instrument
Type
