22
English
Arms
ARMS
WARNING
After ANY adjustments, repair or service and BEFORE use, make sure all attaching
hardware is tightened securely otherwise injury or damage may result.
A. REMOVING OR REPLACING ARMREST (FIGURE 1)
(Removable armrests only)
WARNING
Make sure the armrest is securely locked BEFORE using the wheelchair.
1. Press the armrest release button (A) located on the armrest.
2. Remove the armrest from the arm sockets (B) by pulling straight up.
3. Replace the armrest by reversing STEPS 1-2.
Guardian Plus Models
NOTE:
Armrest may be reversed to allow greater access for propelling.
B. REMOVING FLIP-BACK ARMREST
(4000 Series armrests only)
WARNING
Make sure the armrest is securely locked BEFORE using the wheelchair.
1. Press the armrest release lever located on the armrest.
2. Flip the armrest back.
3. Unscrew bolt at back of armrest and pull armrest up to remove.
4. Replace the armrest by reversing STEPS 1-3.
1
A
B
B
