Guardian 4 - Page 10

- 8 -
5
5. Hold the pedestal and remove the
glucose sensor assembly from the
package. Place the pedestal on a
clean, flat surface such as a table.
6
Correct
tucked tab
Incorrect
6. Confirm that the
adhesive tab of the
sensor is tucked
under the sensor
connector and
sensor snaps.
7
thumb on thumbprint marking
Correct
Incorrect
7. Using either hand,
place a thumb on
the thumbprint
marking to hold the
serter. Fingers must
not touch the serter
buttons.
8
8. Push the serter
down onto the
pedestal until the
base of the serter
sits flat on the table
and there is a click.
