Guardian 4 - Components

- 5 -
Components
BA
One-press serter
A. bump on both buttons
B. thumbprint marking
C
D
A
B
Glucose sensor assembly
A. pedestal
B. needle housing
C. sensor
D. clear liner
A
B
Sensor base
A. sensor connector
B. sensor snaps
Transmitter
BB
A
First piece of oval tape
A. liner 1
B. liner 2
BB
A
Second piece of oval tape
A. liner 1
B. liner 2
