G-MDS86825 (GPI171)
Revised: 2/8/2010
4
Assembly Instructions
IMPORTANT: Read all operating and safety instructions before using your rollator.
Note: You may wish to request a set up and operating demonstration
with your local Medical Equipment provider or pharmacy.
Rollator Components
1 Rollator frame
2 Front wheels
2 Handlebars
2 Rear wheels
2 Knob screws
1 Backrest with push-buttons
2 Round hand screws
1 Basket with handle
Assembled Rollator
A. Handgrips
B. Adjustable Handlebar
C. Padded Backrest
D. Brake Cables
E. Padded Seat
F. Support Rod
G. 8” (203 mm) Front Wheels
H. 8” (203 mm) Rear Wheels
I. Folding Bracket
J. C Clamps
K. Knob Screw
A
B
C
D
F
G
H
J
I
E
L
M
Figure 2:
Knob Screw
K
Figure 1: Assembled Rollator
Front
Back
