ITEM PART NO. QTY. DESCRIPTION
1 087968 1 SWITCH, ROCKER -/0
2 090418 1 OUTLET, 12VDC SNAP
3 0D6640 1 COVER, GOVERNOR CONTROL
4 090987 6 SCREW PPHM M3-0.5 X 12
5 0D8740 1 PANEL, SHEET METAL
6 068868 2 OUTLET 30A 120V RECEPT
7 022985 2 WASHER FLAT #6
8 043182 10 WASHER LOCK M3
9 051714 6 NUT HEX M3-0.5 G8
10 075207A 4 CIRCUIT BREAKER 30A
11 075207 2 CIRCUIT BREAKER 20A
12 0D4969 1 OUTLET 50A 125/250V
13 043437 1 OUTLET 30A 125/250V
14 0D4968 1 OUTLET 20A 120V DPLX
15 0D4966 1 OUTLET 20A 120V GFCI
16 0D1004E 1 CIRCUIT BREAKER 50A 400V
2POLE
17 051716 8 NUT HEX M5-0.8 G8
18 022152 8 WASHER LOCK #10
19 0D5045 1 DIN RAIL 59.5mm LONG
20 067680 1 ASSEMBLY VOLTAGE REGULATOR
60HZ
21 0D4409 1 ELECTRONIC GOVERNOR / IDLE
CONTROLLER
22 052844 1 RELAY PNL 12VDC SPST 30A
23 0F3100 1 RELAY 3PDT 12VDC
24 0D2691 1 CONTROL PANEL BOX
25 023484L 1 BUSHING SNAP
26 0A1661 2 RIVET POP .156 X .160-.164 / #20
27 048766 1 BLOCK TERMINAL 20A 2 X 6 X
1100V
28 0D3550 1 BLOCK DOUBLE ROW TERMINAL 8
POSITION
29 049939 1 RECTIFIER MSC 12A 600V
30 070370 1 WASHER MICA .203
31 030468 1 WASHER STEP NYLON .20
ITEM PART NO. QTY. DESCRIPTION
32 022158 1 NUT HEX #10-32
33 023897 1 WASHER FLAT #10
34 057405 1 RESISTOR 25R 5% 25W
35 022473 1 WASHER FLAT 1/4
36 022097 1 WASHER LOCK M6-1/4
37 049813 1 NUT HEX M6-1.0 G8
38 065795 2 RECTIFIER-BATTERY CHARGER
39 0D4804 2 TRANSFORMER, IDLE CURRENT
40 0C1085 4 SCREW PPHM M3-0.5 X 8
41 051715 18 NUT HEX M4-0.7 G8
42 022264 18 WASHER LOCK M4
43 048505 1 CIRCUIT BREAKER 6 X 1
44 087962 1 CIRCUIT BREAKER 10 X 1 12VDC
1/4"QC
45 036261 2 RIVET POP .125 X .129-.133 / #30
46 0A2769 1 LUG GRND 8 TABS
47 032300 1 HOLDER FUSE
48 028578 1 FUSE 10A X AGC10
49 055444 1 HEATSINK
50 075475 2 SCREW PPHM M4-0.7 X 10
51 049815 4 SCREW HHC M5-0.8 X 16 G8.8
52 0A2053 1 SCREW HHC M6-1.0 X 65 G8.8
53 055440 2 SCREW HHC M5-0.8 X 25 G8.8
54 045770 1 SCREW HHC M5-0.8 X 10 G8.8
55 0D5734 2 SPACER .25 X .50 X 1.5
56 074908 18 SCREW HHTT M5-0.8 X 10
57 075235 1 SCREW PPHM M5-0.8 X 30
58 080823 2 SCREW PPHM M5-0.8 X 50
59 038150 14 WASHER FLAT #8
60 0D6140 1 GASKET, PORTABLE CONTROL
PANEL
61 075476 2 SCREW PPHM M4-0.7 X 16
62 027565 A/R TAPE ELEC UL PERMACEL
63 058000K 2 NUT TRIC M5-0.8
64 0F3101 1 RELAY BASE 3PDT 12VDC
31
Section 7 — Exploded Views and Parts Lists
Commercial-Industrial-Residential Portable Generator System
Control Panel – Drawing No. 0E0227-C
