2. TECHNICAL FEATURES
Definition: solid fuel-burning stove tested according to: EN 13240
Constructive System
*
Rating power in kW 12.5 44,000 btu
Efficiency in % 78.1
Pipe diameter in mm 120 150……(6”)
Maximum quantity of fuel-wood in kg 3.3 7 lbs
Mean content of CO to 13% O
2
in % 0.2667
Emission of exhaust gasses in C° - wood
283.3
Size of hearth opening in mm (W x H) 340x286………………(13.4”x11.25”)
Hearth body size (W x H x P) 450x230 x 334………..(17.7”x9”x13.15”)
Stove height in mm 946…………………….(35.43”)
Stove width in mm 540……………………(21.25”)
Stove depth (with handles) in mm 493…………………….(19.4”)
Weight in kg 155…………………….(341lbs)
Outer smoke output in mm 900…………………….(37.24”)
Accessory: glove
* Hearth door is closed automatically (there is the system for automatic door closing with a spring)
□ * Hearth door is closed automatically
□ * Hearth door is not closed automatically
