Guerrilla Gravity Megatrail - Page 5

Assembly – Fastener Torque
1. Rear Axle
1. Pinch bolt holds axle nut insert and derailleur hanger, to remove rear wheel, only loosen axle head
2. Derailleur Hanger
1. The pinch bolt clamps the nut insert and attaches the derailleur hanger
2. Tighten pinch bolt to 5 Nm (45 in-lb) (5mm hex)
1
2
2
