Assembly - Frame Fittings
– Headset: EC49/40 lower, ZS49/28 for tapered steer tube
– BB: Standard 73mm BSA threaded
– Seat post: Ø30.9mm, Clamp: Ø34.9mm, stealth routing compatible
– Rear hub: 12x148, offset 3mm to the drive side
– Rear brake mount: International Standard
– Shock: 230x57.5, 8x25 front, 8x40 rear hardware
– Tires: Up to 29x2.5”
– Chainring: Up to 34 teeth, 55mm chainline
