21
4. ON / OFF SWITCH
Depress the On/Off switch to start and release it to stop your screwdriver.
5. USING THE SIGHTLIGHT
To turn on the light simply press the on/off switch. When you release the on/off switch,
the light will be off.
Maintenance
Your power tool requires no additional lubrication or maintenance.
There are no user serviceable parts in your power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power
tool in a dry place. Keep the motor ventilation slots clean. Keep all working controls free
of dust. Occasionally you may see sparks through the ventilation slots. This is normal
and will not damage your power tool.
Technical Data
Charger voltage 100-240V ~ 50/60Hz
Battery voltage 3.6V
Battery capacity 1.3Ah Li-ion (4.68Wh)
No load speed 180/min
Max torque 4N.m
Charging time
3-5hr
Charger Input 100-240V~50/60Hz,5W
Charger Output
5V
500mA
Machine weight
0.31kg
Technical Data Table
Operating Instructions
