Circuit Breaker Name: CB Panel: Location: Power Source:
SPLR FLT PWR S/O CPOP E-3 R ESS DC Bus
AIL TRIM HEAT REER D-16 R MAIN AC Bus
B. Crew Alerting System (CAS) Messages:
The following CAS messages are associated with the roll flight controls
system:
Area Monitored: CAS Message: Message Color:
L / R Aileron Hydraulic Actuators L - R Aileron Hydraulics
Off
Amber
Spoiler Control Switch Spoilers Hydraulic Off Amber
Aileron Trim Tab RVDT and
Autopilot Aileron Servos
Retrim Left Wing Down Amber
Aileron Trim Tab RVDT and
Autopilot Aileron Servos
Retrim Right Wing Down Amber
4. Limitations:
There are no limitations established for the aileron roll control system at the time
of this writing.
OPERATING MANUAL
PRODUCTION AIRCRAFT SYSTEMS 2A-27-00
Page 41
August 14/03
