Gulfstream Monaco 9660 - INSTALLATIONS; Typical Discharge Pump Installation; Typical Gravity Sink (Direct Drain) Installation

P-Trap
Gravity Sink
2’’ - 3’’ drain pipe
to sewer line
3/8” Hot & Cold Hoses
Floor
20’’-24’’
INSTALLATIONS
10
Typical Discharge Pump Installation
Typical Gravity Sink (Direct Drain)
Installation
Floor
20’’-24’’
3/8” Hot & Cold Hoses
Existing Drain Pipe
Wall
GFI Outlet Required
Backwater valve sold
separately
Existing 3/8” Hot & Cold
Water Supply
Check Valve
(not supplied)
Wall
GFI Outlet Required
Existing 3/8” Hot & Cold
Water Supply
Backwater valve sold
separately
Floor
P-Trap supplied by plumber
