WALL CLEARANCE
FOOT-SPA CLEARANCE
5
Wall
36.75’’
20" Minimum
Distance from center drain
to the back of the spa
TYPICAL FOOT-SPAS
60’’
60’’
16’’16’’ 16’’ 16’’
Foot-spa #1
Center
Center
Foot-spa #2
Clearance
24’’ 24’’
