The stall barrier system is constantly monitored for faults or failures.
If a fault or failure in the control column pusher is detected,
messages are prompted for display on CAS.
(3) Angle of Attack Probe:
Two heated Angle of Attack (AOA) probes provide aircraft AOA
information via the Aeronautical Radio Incorporated (ARINC) 429
databus to the DAUs. The left AOA probe provides information to
DAU #1 and the right AOA probe provides information to DAU #2.
AOA values are displayed on the Primary Flight Display (PFD).
The AOA system is constantly monitored for faults or failures. If a
probe heater failure occurs, or data transmitted by the probes to
their respective DAUs is in gross disagreement, messages are
prompted for display on CAS.
3. Controls and Indications:
(See Figure 3 through Figure 6.)
NOTE:
A full description of the Primary Flight Display can be
found in section 2B-02-00: Electronic Display System
Description. A full description of the FLIGHT
CONTROLS synoptic page can be found in section
2B-03-00: Engine Instruments and Crew Alerting
System Description.
A. Circuit Breakers (CBs):
The pitch flight controls system is protected by the following CBs:
Circuit Breaker Name: CB Panel: Location: Power Source:
L ELEV TRIM HEAT REER E-16 R MAIN AC Bus
R ELEV TRIM HEAT REER F-16 R MAIN AC Bus
LEFT ELEV HYD S/O POP C-5 L ESS DC Bus
RIGHT ELEV HYD S/O CPOP C-5 R ESS DC Bus
STALL BARR VALVE #1 POP E-5 L ESS DC Bus
STALL BARR VALVE #2 CPOP E-5 R ESS DC Bus
SHAKER #1 POP E-6 L ESS DC Bus
SHAKER #2 CPOP E-6 R MAIN DC Bus
AOA PROBE #1 POWER LEER F-4 L ESS DC Bus
AOA PROBE #2 POWER REER F-13 R ESS DC Bus
B. Crew Alerting System (CAS) Messages:
CAS messages associated with the pitch flight controls system are as
follows:
Area Monitored: CAS Message: Message Color:
Stall Warning System AOA MISCOMPARE Amber
AOA Probe(s) AOA PROBE 1/2 FAIL Amber
Integrated Avionics Computer(s) EL MISTRIM NOSE DN Amber
Integrated Avionics Computer(s) EL MISTRIM NOSE UP Amber
OPERATING MANUAL
PRODUCTION AIRCRAFT SYSTEMS 2A-27-00
Page 9
May 22/01
