7.1.10.1 Replacing the filter sleeves on a 41
Shake filters and allow
dust to settle.
Remove front panel by
unhooking latches.
Remove large worm-drive
clip from base of each filter
sleeve.
Unhook top of each filter
from retainer clip.
Carefully remove filter
from dust collector.
Replace with new filter
sleeve (Y1CA0000) by
hooking top of filter onto
retainer clip first then pass
worm drive clip over the
base of the sleeve and
secure to base of dust
collector. Re-fit front
cover.
