H3C S6520X-EI Series User Manual

Table1-2 Technical specifications (2)
Item S6520X-30HF-EI S6520X-54HF-EI S6520X-30HF-HI S6520X-54HF-HI
Dimensions
(H × W × D)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
44 × 440 × 360 mm
(1.73 × 17.32 ×
14.17 in)
Weight ≤ 5.5 kg (12.13 lb) ≤ 6.0 kg (13.23 lb) ≤ 6.0 kg (13.23 lb) ≤ 6.5 kg (14.33 lb)
Console port 1 × serial console port
Management
Ethernet port
1 1 1 1
USB port 1 1 1 1
SFP+ port 24 48 24 48
QSFP28 port 6 6 6 6
Fan tray slot 3 3 3 3
Power supply
slot
2 2 2 2
Input voltage
AC input for the PSR180-12A-F/PSR180-12A-B power supply:
• Rated voltage range: 100 to 240 VAC @ 50/60 Hz
• Max voltage range: 90 to 264 VAC @ 47 to 63 Hz
Minimum
power
consumption
• 29 W with one
PSR180-12A-F
/PSR180-12A-
B
• 35 W with two
PSR180-12A-F
/PSR180-12A-
B
• 29 W with one
PSR180-12A-F
/PSR180-12A-
B
• 36 W with two
PSR180-12A-F
/PSR180-12A-
B
• 38 W with one
PSR180-12A-F
/PSR180-12A-
B
• 46 W with two
PSR180-12A-F
/PSR180-12A-
B
• 36 W with one
PSR180-12A-F
/PSR180-12A-
B
• 44 W with two
PSR180-12A-F
/PSR180-12A-
B
Maximum
power
consumption
• 131 W with one
PSR180-12A-F
/PSR180-12A-
B
• 134 W with two
PSR180-12A-F
/PSR180-12A-
B
• 162 W with one
PSR180-12A-F
/PSR180-12A-
B
• 163 W with two
PSR180-12A-F
/PSR180-12A-
B
• 143 W with one
PSR180-12A-F
/PSR180-12A-
B
• 145 W with two
PSR180-12A-F
/PSR180-12A-
B
• 176 W with one
PSR180-12A-F
/PSR180-12A-
B
• 177 W with two
PSR180-12A-F
/PSR180-12A-
B
Melting
current of
power supply
fuse
6.3 A @ 250 VAC
Operating
temperature
–5°C to +45°C (23°F to 113°F)
Humidity 5% RH to 95% RH, noncondensing
Safety
specification
compliance
UL 62368-1/EN 62368-1/IEC 62368-1/UL 60950-1/EN 60950-1/IEC 60950-1/GB4943.1
