H3C S6850-56HF

66
NOTE:
• You can use a QSFP-40G-SR4-MM850 or QSFP-40G-CSR4-MM850 transceiver module to
connect a QSFP+ port to four SFP+ ports. The QSFP+ transceiver module and SFP+ transceive
r
modules to be connected must be the same in specifications, including central wavelength and
fiber type.
• Interface numbered 31 on the S6850-56HF and S9850-32H switches cannot be split into four
interfaces.
• When the LSWM18CQ or LSWM18CQMSEC interface module is installed in slot 2 on the
S9850-4C switch, interface numbered 7 on the interface module cannot be split into four
interfaces.
• When the LSWM124TG2H interface module is installed in slot 2 on the S9850-4C switch, the
interface numbered 25 on the interface module cannot be split into four interfaces.
Table 19 QSFP28 transceiver modules available for the QSFP28 ports
QSFP28
transceiver
module
Central
wavelength
(nm)
Connector
Fiber type and
diameter (µm)
Modal
bandwidth
(MHz*km)
Maximum
transmission
distance
QSFP-100G-
SR4-MM850
850
MPO (PC
polished,
12-fiber)
Multi-mode,
50/125
2000 70 m (229.66 ft)
4700 100 m (328.08 ft)
QSFP-100G-
PSM4-SM13
10
1295 to 1325
MPO (APC
polished,
12-fiber)
Single-mode,
9/125
N/A 500 m (1640.42 ft)
QSFP-100G-
LR4-WDM13
00
Four lanes:
• 1295
• 1300
• 1304
• 1309
LC
Single-mode,
9/125
N/A 10 km (6.21 miles)
QSFP-100G-
LR4L-WDM1
300
Four lanes:
• 1264.5 to
1277.5
• 1284.5 to
1297.5
• 1304.5 to
1317.5
• 1324.5 to
1337.5
LC
Single-mode,
9/125
N/A 2 km (1.24 miles)
QSFP-100G-
SWDM4-MM
850
Four lanes:
• 850
• 880
• 910
• 940
LC
Multi-mode,
50/125
2000 75 m (246.06 ft)
4700 100 m (328.08 ft)
IMPORTANT:
QSFP-100G-SWDM4-MM850 is available only in E6553 and later versions.
