3-29
Logging in from the serial console port or micro USB console
port
When you connect the console cable, identify the port marks and make sure y
the correct ports.
The serial ports on PCs do not support hot swapping. To connect a PC to an operating firewall,
first connect the PC end. To disconnect a PC from an operating firewall, first disconnect the
To access and manage the firewall locally, connect the serial console port or the micro USB console
port on the firewall to a configuration terminal (a PC for example). Only the micro USB console port is
available if you connect both the serial console port and micro USB console port.
By default, the firewall uses the scheme access authentication mode. The username and password
are both admin.
To configure and manage the firewall through the serial console port or micro USB console port, you
must run a terminal emulator program, TeraTermPro or PuTTY, on your configuration terminal and
configure the following settings for the terminal. For more information about the terminal emulator
programs, see the user guides for these programs.
Bits per second—9600.
Data bits—8.
Stop bits—1.
Parity—None.
Flow control—None.
Logging in through Telnet
1. Log in to the firewall through the serial console port or micro USB console port, and enable the
Telnet function in system view by using the
telnet server enable command.
2. Enter VTY user line view, and configure the authentication mode, user role, and common
properties in VTY user line view.
By default, the authentication mode is scheme, and the username and password are admin.
3. Connect a PC to the Ethernet management port GigabitEthernet 1/0/0 (0/MGMT) on the
firewall.
4. Specify an IP address for the network port of the PC. The IP address must be in subnet
192.168.0.0/24 and cannot be 192.168.0.1.
5. Run the Telnet client on the PC and enter the default login information.
