H3C WX5500H series Configuration Guide

4
cloud-management server domain domain-name
By default, the domain name of the H3C Oasis server is not configured.
3. (Optional.) Set the keepalive interval.
cloud-management keepalive interval
By default, the keepalive interval is 180 seconds.
4. (Optional.) Set the ping interval.
cloud-management ping interval
By default, the ping interval is 60 seconds.
5. (Optional.) Specify the TCP port number used to establish cloud connections.
cloud-management server port port-number
By default, the TCP port number used to establish cloud connections is 19443.
Unbinding the device from the Oasis server
About this task
A device can be registered on the Oasis server by only one user.
To register a device that has been registered by another user, you need to take the following steps:
1. Obtain a verification code for device unbinding from the Oasis server.
2. Execute the command on the device for sending the verification code to the Oasis server.
3. Register the device on the Oasis server.
Procedure
1. Enter system view.
system-view
2. Send the verification code for device unbinding to the Oasis server.
cloud-management unbinding-code code
Display and maintenance commands for cloud
connections
Execute display commands in any view.
Task Command
Display cloud connection state information.
display cloud-management
state
Cloud connection configuration examples
Example: Configuring a cloud connection
Network configuration
As shown in Figure 2, configure the AC to establish a cloud connection with the H3C Oasis server.

H3C WX5500H series Specifications

General

Brand	H3C
Model	WX5500H series
Category	IP Access Controllers
Language	English
