Haan SELECT SI-60 - Product Assembly and Pre-Use Checks; Component Identification and Assembly

6
Handle Assembly:
Line up groove &
insert into unit.
Floor Setting Indicator Light:
Ideal for ceramic, stone, tile and
other durable floors.
Perfect for sealed hardwood,
laminate, bamboo and other
delicate floors.
Product Assembly & Parts
1
5
6
7
8
9
10
11
12
14 15
13
16 17
2
3
4
A
B
Base Assembly:
Insert screw as shown. Tighten using
a flat-head screwdriver. If screw
turns freely without “gripping” the
insert threads, apply additional pres-
sure when turning.
