OPERATION_
SICKLii HAH MOWER FOR I-11 CUB
CADET TRACTOR
Your Haban Sickle Bar Mower can be stopped
orslartedby using I-H Cub Cadet P.T.O.
Atlachmont clutch on the side of the tractor.
(Refer to tractor instruction manual on pro¬
per method of clutching and dc-clutching
attachments used with tractor.)
NEVER leave the tractor engine running when
dismounting from the tractor. De-clutch trac¬
tor P.T.O. clutch as well.
Always stop U'actor engine when dismounting
from tractor-set tractor in "park” |X)silion
-transmission should be In neutral. Always
de*clutch tractor PTO whenever slopping trac¬
tor engine, or tractor operation.
KT MAN OLE
OPKKATING rostricA
TO INCREASn TENSION
ON TORSION SPKINC.
TIGHTEN HOLT. INCH EASED
TCNSION REMOVES WEIGHT
FROM OUTER SHOE. LESS
TKSSKXi ADOS WEIGHT
TO OLTFR
IN THIS POSITION
ron OPERATION, pirr
HANDLE IN "UP" POSI¬
TION WHEN DETACHING
MOWEK PUOM TicU'iuU
LIFT SPRING TKNSIW WITH
PIVOT IIAKDI.E IN OPERATING
POSITION. SHOULD CARRY
INNER SHOE (F) i/8*'OKK
GROUND. SHOE CLEARANCE
FROM GROUND CAN HE IN¬
CREASED BY DKOPHNO LINKS
IS LIFT CHAIN <D)... CUTTING
CONDITK^S IN SOME AH^:A.S
MAY RCUmRE INNER SHOE
CLEARANCE FROM GROUND
OK APPROX, 2'* WHEN IN
OPBKATING POSITION ON
LEVEL GROUND.
IF TORSION SPRING IS iXXfSr.,
SICKLE RAH WILL DE HARD TO
LIFT. IF TORSION SPRING IS
SET TOO nCIIT. OUTER ► NDOF
SICKI.H RAR WILL HAVE A TEND-
OiCr TO HOUNCKIN OPERATION.
HOLD DOWN CLIPS
SHOULD HAVE
1/32'* CLEARANCE
FKOM .SICKLE KNIKE
Ftg. 1
^ Keep lock strap (ID in place.
Fig. 2
4
LIMIT STOP (Figure NORMAL CUTTING: The
limit stop (5) should be set with lOCK OUT
STRAP (H) in place on slot. Thi.s will limit the
travel of the Cutler Bar in culling (K)sition
to approximately 70® above ground level and
allow it to function to it8 niii.ximumbcIowgroun<l
level. The lift arm must always be set in
operating position (B) when cutting.
VERTICAL CUTTING (90^ only) The lockout
strap (H) must be removed to cut 9(K a)x>vo
ground level or vertical. When finished with
vertical cutting, bolt strap (H) Ixick in place.
The lift arm must always bo sot in operat¬
ing position (c) when vertical cutting.
CAUTION: Make sure lockout strap(H) is Iwltinl
securely in place when finished with vertical
cuttings.
Form 8512 (4/72)
