OPERATION
Fig:-3
OPERATING
POSITION
HR EAK-JiACK
POSITION
POSITION 2
SWATH
KDCK
Fig. 4
TRANSPORTING MOWERi
Shut off tractor engine and disengage tractor
P.T.O. clutch. Install sickle knife cover (F)
using retaining strap to secure cover to bar.
Set lift handle in transport position (A), Stand
in back of mower^ raising mower bar with
right hand to vertical position* Insert trans'*
port pin (D) as illustrated by sliding pin down
from vertical to horizontal position as shown
by arrow* Let pin slide through hole in strap
(G) to lock in place. Avoid sudden or sharp
turns with mower in transport position (Fig*3).
TO CHANGE SICKLE BAR MOWER FROM
TRANSPORT POSITION TO MOWING TOSITION;
Shutoff tractor engine. Standing behind mower
push inward on mower bar* slide transport pin
<D) out of strap (G) and turn strap to vertical
position to lock out. Lower sickle bar to
ground. Loosen retaining strap (C) and remove
sickle knife guard* Always install sickle knife
guard when mower is notin use or when trans*
porting unit.
CUTTlNGt
nefore ope ration,check complete unit for any
looseness which may have occured in shipping.
Unit should then be operated a short period
to check for proper assembly and adjustments
before actual cutting begins. Stop and rechcck
all parts after 30 minutes of operation and
rctlghtcn loose parts. Also follow lubricating
instructions found on page 12. Operate tractor
at full throttle. It will be necessary to regulate
tractor forward travel to meet existing cutting
conditions, which can vary greatly* depending
on material that is being cut. HUN INNER
SHOE APPROXIMATELY 4" AWAY FROM
PREVIOUS SWATH EDGE FOR BEST PER¬
FORMANCE. Cutter bar has additional width
of cut to compensate for overlay. Care must
be exercised not to operate tractor at ex¬
cessive ground speed when cutting rough ter¬
rain. The lift arm must always be set in
operating position (B) when cutting.
Under severe conditions the sickle knlve.s
should be sharpened after every four hours
of operation. Additional knives and rivets are
available for repairs, which makes it possible
to always have a sickle knife assembly in
good repair if one becomes daninged or worn.
