Page #5 background imageLoading...
Page #5 background image
General Instructions for 230v Machines...
DO NOT use this machine within the designated safety areas of flammable
liquid stores or in areas where there may be volatile gases. There are very
expensive, very specialised machines for working in these areas, THIS IS
NOT ONE OF THEM.
Check that cutters, drills, blades etc., are the correct type and size, are undamaged
and are kept clean and sharp, this will maintain their operating performance and lessen the
loading on the machine.
If possible always fit dust extraction to machines that are producing high rates of sawdust,
shavings, chips etc.
Above all, OBSERVE…. make sure you know what is happening around you, and USE
YOUR COMMON SENSE.
REMEMBER, YOU ARE ULTIMATELY REPONSIBLE FOR YOUR OWN SAFETY
THIS MACHINE IS DESIGNED TO CUT TIMBER AND TIMBER DERIVATIVE
PRODUCTS. DO NOT use for any other materials.
Specification
MJ2325D
Motor Single phase 230V, 50 Hz
Motor Power 2.2 Kw
Motor Speed 2840 rpm
Blade Diameter 10" (254mm)
Bore Size 25.4mm
Blade speed 2840 rpm
Table Size 560mm x 800mm
Table Size with 2 side extensions fitted (305 X 800 ea.) 1170mm wide x 800mm deep
Table height 845mm
Tilt Angle 0-45 degrees
Minimum Kerf 3mm
Maximum Depth of Cut (at 0 degrees) 10" (75mm)
Maximum Depth of Cut (at 45 degrees) 10" (60mm)
Lpa (sound pressure) dB(A) 99.5
Lwa (acoustic power) dB(A) 112.5
Weight 10" (260kgs) )
