LOOX Mounting / Programming Instructions: Item no. 833.74.708

Installing the Battery
 To install or replace the battery (type CR2032, 3V), remove battery
cover.
 Pay attention to battery orientation (+ faces the battery cover).
 Slide battery cover into place until the cover snaps closed.


Pairing the Wireless Remote to the Mixer Module:
 Press button located on Mixer Module Top Cover.
 Button will illuminate solid blue....
 Press S1+S3 buttons together on Wireless Remote.
 The Blue light on the Receiver Module will turn off, on and back off.
