hager Tebis TX 100 User Manual

3
Dialing and product research phase
Num. How to...
3
To dial outputs just
added to an exis-
ting installation…
Solutions
1
Phase configuration ou programmation
Num.
Que faire pour...
4
To program the
extension of an
Easy installation
via ETS.
Solutions
2
2
Dialing and product research phase
1
Num.
How to...
1
To order the auto-
matic dialing of
outputs.
Solutions
2
To dial the inputs.
- Make sure that no output product (wire and radio) is under voltage.
- Set the configurer in mode 'prog'.
- Make a long pressure of key to start the automatic search of outputs.
- Connect the first product.
- Wait until the number of outputs is incremented on the screen of TX100 (e.g. 6
outputs for TX206A).
- Connect the following product and wait again until the number of outputs is
incremented on the screen of TX100.
- Use the same procedure for completing the installation.
Set TX100 in mode Num'.
Modular wire inputs: Press pushbuttons on TX314 and TX316 product front face or
pushbuttons connected to the inputs.
Modules to be embedded in unidir: press the pushbutton associated with the desired
input and follow the instructions of TX100.
Remote controls: press the key to dial and follow instructions of TX100.
Radio module bidir: press the pushbutton connected to the desired input.
Wire products to be embedded: press the pushbutton connected to the desired input
Presence detector: Set the product in test mode (potentiometer in position
''Test'').
Clock: Press key (A or B) corresponding to the desired channel.
Dimmer switch: Press the pushbutton of product front faceRoom controler: Press the
sensitive keys to be dialed.
- Set the configurer in mode 'prog'.
- Give the key a long press to start the automatic search of outputs.
- The configurer seeks and dials automatically all new outputs present in the
installation.
- Refer to §4 page 12 of TX100 User's Instructions.
- First of all, check if "ETS Mode" is activated: See § 11 on page 28 of TX100
instructions.
Note: this mode is active by default,
- If the ETS mode is deactivated perform installation factory return (including unidir
products), activate "ETS mode" and delete Smart Media Card; then reconfigure the
installation.
