hager Tebis TX 100 User Manual

6
Configuration or programming phase
Num.
How to...
7
Special case:
To configure and
set a modifiable
scenario for rolling
shutters.
Solutions
2
7
Configuration or programming phase
Num. How to...
8
Special case:
To configure and
set a modifiable
scenario for blinds.
Solutions
2
The position of the blind is configurable for scenarios 1 to 5.
- Set up the total lowering time of the blind (see item No.10).
- Dial the input intended to activate the scenario.- Choose the configurable scenario
function (S1 to S5)- Establish a link between this input (push-button) and all outputs
concerned.
Note: The creation of link is described in User’s Instructions TX100.
- Return to mode «auto».
- Activate the scenario by a short press of corresponding input scenario.
- Position the blinds in high position, if necessary.
- Lower the blinds in the position desired with the local control.
- Then incline the slats (by short presses) until the desired position is reached (only
for the S1 scenario); this inclination will be taken into account for all configurable
scenarios.
Note: Do not start any raising during this setting, if not do this proce-
dure again.
- Store the scenario by a long press (5s) of pushbutton to activate the scenario (for
time switch and dimmer switch to see item No.9).
Note: The position restored following activation of scenarios S2 to S5
corresponds to the position nearest to one of4 positions avai-
lable (high, 1/4, 1/2, and low) and the inclination of the slats
corresponds to that configured for scenario S1 (0 inclination by
default).
The position of the shutter is configurable for scenarios 1 to 5.
- Set up the total lowering time of the rolling shutter (see item No.10).
- Dial the input intended to activate the scenario.
- Choose the configurable scenario function (S1 to S5).
- Establish a link between this input (push-button) and all outputs concerned.
Note: The creation of link is described in User’s Instructions TX100.
- Return to mode “auto”.
- Activate the scenario by giving the corresponding scenario input a short press
- Position the rolling shutters in high position, if necessary.
- Lower the shutters in the position desired with the local control.
Note: Do not perform any raising during this setting, if not redo this
procedure.
- Store the scenario by giving a long press (5s) to the activation pushbutton of sce-
nario (for time switch and dimmer switch to see item No.9).
Note: The position restored following activation of scenarios S2 to S5
corresponds to the position nearest to one of the 4 available
positions (high, 1/4, 1/2, and low).
