Specification
Domestic air conditioner
TECHNICAL SPECIFICATIONS-OTHERS
Refrigerant
circuit
Refrigerant type R32
Refrigerant charge KG
1.1
Maximum allowable distance
between indoor and outdoor
m
30(double)
20(single)
Maximum allowable level difference m 15
Refrigerant control EEV
Piping connections
(external diameter)
liquid mm 6.35
gas mm 9.52
drain mm 16
Heat insulation type Both liquid and Gas pipes
Max. piping Length m
Max. Level Difference m 15
Chargeless m 20
Amount of Additional Charge of Refrigerant g/m 20
Note: the data are based on the conditions shown in the table below
htgnelgnipiPgnitaehgnilooc
Indoor: 27 DB/19 WB
Outdoor: 35 DB/24 WB
Indoor:20 DB
Outdoor: 7 DB/6 WB
5m
3 Sensors list
Conversation formulae
Kcal/h= KW×860
Btu/h= KW×3414
cfm=m³/min×35.3
30(double) 20(single)
type Description Qty
itcetedrofdesustIrosnestneibmA edisroodtuofoerutarepmetgn
Suction sensor
Its used for detecting suction pipe temperature of compressor to
adjust gas flowing
1
Defrosting sensor Its used for controlling outdoor defrosting at heating mode 1
taeh-revofoesacnirosserpmocrofdesustIrosnesgnigrahcseD
Liquid-gas pipe
sensor
Its used for adjusting the valve opening of the electric expansion
2
valve.
