Parts and Functions
CAUTION
Before opening the front grille, be sure
to stop the operation and turn the
breaker OFF.
Do not touch the metal parts on the
inside of the indoor unit, as it may result
in injury.
ON/OFF button
Push once to start operation,
push once again to stop it.
Operation is set to AUTO, air
flow is set to AUTO FAN.
(page 9)
Use when remote controller is
not available.
Receiver
Signals are received from the remote
controller here.
Upon receiving a signal, there is a receiving
sound.
Air outlet selection switch
This setting blows air from upper outlet only.
This setting automatically decides a blow
pattern depending on mode and conditions.
This setting is
recommended.
The unit is shipped from the
factory with this setting.
Air outlet
selection
Room temperature sensor
Senses the air temperature around the unit.
6
