Domestic air conditioner
Sensors list
TECHNICAL SPECIFICATIONS-PARTS
cooling heating
Fan
Cross flow fan Type
40 W Motor output
Air flow rate(high) m³/h
510
Speed(super/high/low) rpm 1200/1180/950
Heat exchanger
Type
ML fin-φ7HI-HX tube
3*12*1.4 Segment *stage*fitch
Air direction control Right,Left,Horizontal,Downward
Air filter
Removable/Washable/Mildew Proof
Note: the data are based on the conditions shown in the table below
Piping lengthheating cooling
Indoor: 27℃DB/19℃WB
Outdoor: 35℃DB/24℃WB
Indoor:20℃DB
Outdoor: 7℃DB/6℃WB
7m
4．Sensors list
Conversation formulae
Kcal/h= KW×860
Btu/h= KW×3414
cfm=m³/min×35.3
type Description Qty
1Room and pipe sensor Its used for detecting room and evaporator temperature
