10.3 Error Codes and Description indoor display
Code indication
fault description
Reference
Page
Indoor displaying panel code
indication
Outdoor
(LED1
flash
times)
Other
display
Only For 498 and
498A display
(Red/Green Time Run
ƶ2Qƾ)ODVKƵ2II ,)
Indoor and
Outdoor
E7
ƵƵƾ
15
Communication fault
between indoor and
outdoor units
Page .39
Indoor
Malfunction
E1
ƾƵƵ
--
Room temperature sensor
failure
Page 29
E2
ƾƶƶ
--
Heat-exchange sensor
failure
Page 29
E4
ƾƶƾ
-- Indoor EEPROM error Page 30.
E9
ƾƾƾ
21
High-work intense
protection
Page 42
E14
Ƶƶƾ
--
Indoor fan motor
malfunction
Page 31
Outdoor
Malfunction
F12
ƵƾƵ
1 Outdoor EEPROM error Page .30
F1
ƶƾƾ
2 The protection of IPM Page .34
F22
ƾƾƵ
3
Overcurrent protection
of AC electricity for
the outdoor model
Page .35
F3
ƵƾƵ
4
Communication fault
between the IPM and
outdoor PCB
Page.36
F19
Ƶƾƶ
6
Power voltage is too high
or low
Page .37
F4
ƵƾƵ
8
Overheat protection for
Discharge temperature
Page .38
F21
ƶƶƾ
10
Defrost temperature
sensor failure
Page 29
F7
ƵƾƵ
11
Suction temperature
sensor failure
Page.29
F6
ƶƾƵ
12
Ambient temperature
sensor failure
Page 29
F25
ƾƶƵ
13
Discharge temperature
sensor failure
Page 29
F11
ƵƾƵ
18
deviate from the normal
for the compressor
Page .41
F28
ƵƾƵ
19
Loop of the station
detect error
Page .41
F2
Ƶƾƶ
24
Overcurrent of the
compressor
Page .35
F8
Ƶƾƶ
9
Outdoor DC fan motor
fault
Page 32
F23
Ƶƾƶ
25
Overcurrent protection for
single-phase of the
compressor
Page .35
