Haier CFE633CSE Service Manual

SERVICE MANUAL
Model: CFE629CW
8
Issue 2009-12-23
Rev. Ref0912S021V0
Ice cube tray(s)
n° 1
Butter holder
yes
Egg trays
2
Adjustable feet front / rear
n° 2 / -
Length of cable/incl. plug
cm 200
Condenser Back wall / Integrated
B
6
Product dimensions
Unit dimensions ( H / W / D)
cm 188/59.5/67
Depth Without handle
cm 67
Depth with open door
cm 1188
Door open angle
n° <135
Net weight
kg 76
7
Packing dimensions & load ability
Packing dimensions (H / W / D)
cm 184.2/65.7/71.7
Gross weight
kg 80
40 ' Container load
pcs 54
40 ' HC Container load
pcs 72
8
Recycling symbols
Packing materials / Recycling symbols (RS)
RS RS
Carton weight in gr
6270
Polystyrene weight in gr
06 2570
Polyethylene foil weight in gr
04 210
9
Service
Users instruction (languages)
D / F / I / GB / E / P / NL
2-2 Main Functions and Features
◆ Energy saving and convenience (only in some models).
◆ Half-shelf structure.
◆ Innovative long-efficiency lighting system.
◆ Foldaway wine holder.
◆ Large crisper with humidity adjustment.
◆ Holiday function.
◆ Power ON/OFF function is set on the display panel (only in some models).
◆ Fridge storage compartment can be set on/off separately.
◆ Intelligent alarm function: automatic alarm at over temperature, malfunction, door open.
◆ Touch keys (only in some models).
◆ Deodorizer (only in some models).
◆ Zero degree fresh keeping.

Haier CFE633CSE Specifications

General

Door hinge	Right
Control type	Rotary, Touch
Product color	Silver
Built-in display	No
Reversible doors	Yes
Appliance placement	Freestanding
Number of compressors	1
Noise level	42 dB
Climate class	SN-T
Total net capacity	310 L
Total gross capacity	342 L
Lamp type	LED
Fridge net capacity	230 L
Fridge door balconies	4
Fridge gross capacity	- L
Fridge number of shelves/baskets	3
Star rating	4*
Freezer position	Bottom-placed
Freezing capacity	11 kg/24h
Freezer net capacity	80 L
Storage time during power failure	18 h
Connected load	- W
AC input voltage	220 - 240 V
AC input frequency	50 - 60 Hz
Annual energy consumption	319 kWh
Package depth	717 mm
Package width	657 mm
Package height	1947 mm
Package weight	86000 g

Weight and Dimensions

Depth	670 mm
Width	600 mm
Height	1880 mm
Weight	76000 g
