FLOWCHECK DISTRIBUTORS: Outdoor units use the Flowcheck Distributor to act as an open check
valve in the cooling mode.
Fig.1-4
ACCESSORIES:
CABINETS:
Constructed of powder painted galvanized steel to provide
a durable finish
and protection for the outdoor coil.
FAN GUARD AND MOTOR BRACKET:
BASE PAN: This deep-drawn base keeps the bottom of the coil off the
ground, has weep holes to allow for complete drainage.
LOW AMBIENT CONTROL: This factory installed option allows for low temperature operation in
the cooling cycle ambient temperatures down to 0
. This control should be installed in units that
operate in cooling when outdoor
ambient temperatures below 65
, and is recommended for all
commercial applications.
and system pressure combinations. This option maybe required on reciprocating compressors with
START COMPONENTS : This option provides additional starting for covering a wide range of voltages
SERVICE VALVES AND PRESSURE PORTS: Mounted external to the cabinet for easy access at
installation and during service.
Welded powder coated guard with independent rod and band motor
SERVICE VALVES: Facilitates unit servicing and provides a reliable and
bracket, unit top has a deep draw fan venturi for efficient air flow.
flowcheck piston metering.
Central Air Conditioner Model: Cooling Only, 13SEER units
