Haier HDHP80AN1 User Manual

8
11 English |
CONTROL P
ANEL
5
Filters must be cleaned regularly.
See Lint Filter Cleaning or Condenser
Filter Cleaning section of the manual.
Clean filter
indicator
2
Childlock indicator
To activate the Child-lock function after a cycle
has been started, press the Childlock
button
for 3 sec. until the indicator icon lights up.
To deactivate press the button for 3 sec. again.
Note: When the cycle ends or the power
supply is interrupted, the function will not be
cancelled automatically.
Note: After each cycle, indicator will flash to
remind cleaning the filters.
Delay function for delay start, press the button to
set time (in 1 intervals up to 12 hours).
The appliance shoule be finished in, afterwards
press to start the delayed operation.
1
Delay button
3
Timer indicator
When choose the timer program, It will lights up.
Signal indicator
You can choose signal as you need. To active
the signal function after switching on the dryer,
press
and Temp. for about 3 seconds
until the beep sounds.To deactivate press both
buttons for 3 seconds again until the beep sounds.
4
Note: This function should be set after you
have finished all the options, otherwise when
you turn the knob or press the button, the
function will be delected automatically.
3.1 Pictur
e of appliance
Front (Fig. 3-1): R
ear side (Fig. 3-2):
Due to technical changes and different models, the illustrations in the following
chapters may differ from your model.
1 Water tank
2 Door
3 Control panel
4 Power supply cord
5 Back plate
6 Drainage outlet
7 Adjustable feet
User manual
Drain hose
Energy Label
Drying Rack
3.2 Accessories
Check the accessories and literature in accordance with this list (Fig.3-3):
3-3
NZ AU
Notice
3-Product Description
1
3
2
4
5
6
7
3-1
3-3-22
