Haier HF50CM23NW Service Manual

SERVICE MANUAL
Model: HF50CM23N
W
/
HF71CM33N
W
11
Issue 2014-04-12
Rev.
Ref1404S005V0
4-4. Thermostat assembly
First take off the knob (refer 4-3), Use turnbuckle spanner or acutilingual plier unscrew the turnbuckle,
and then thermostat can be moved from back of panel.
Note: When assembly thermostat we should placed thermostat in originally direction.

Haier HF50CM23NW Specifications

General

Brand	Haier
Model	HF50CM23NW
Category	Freezer
Language	English
