18 Connection description
①②③④⑤⑥⑦⑧
1 Place the cooler in parallel to the freezer properly with about 10 mm clearance left between them and keep
appropriate working space around two refrigerators.
2 Connect the two refrigerators beginning from the back parts.
2.1 Knock the rear upper connector
①
into the weld seam between two refrigerators to connect their rear
upper parts.
2.2 Insert the rear lower connector
②
into the side edge of the compartment, and use screws
⑧
to connect
their rear lower parts.
