Notes:
1-
120-second fan delay for air handler
2- R-22 Charge for the outdoor unit with matching indoor unit and 25' line set.
Central Air Conditioning Model: Heat Pump, HR13-D2
HR18D2VAR HR24D2VAR HR30D2VAR HR36D2VAR
1.5-Ton Outdoor HP 2-Ton Outdoor HP 2.5-Ton Outdoor HP 3-Ton Outdoor HP
New Model New Model New Model New Model
Model Number
Comments
Model Status
Height 26 7/8 26 7/8 26 7/8 30 3/8
Width 24 1/4 24 1/4 24 1/4 24 1/4
Depth 24 1/4 24 1/4 24 1/4 24 1/4
Cubic Volume (Cu. Ft) 9.15 9.15 9.15 10.34
3/8" 3/8" 3/8" 3/8"
3/4" 3/4" 3/4" 7/8"
115 115 115 115
Outdoor above Indoor Unit 70 70 70 70
Indoor above Outdoor Unit 50 50 50 50
Re-usable Re-usable Re-usable Re-usable
Sweat Sweat Sweat Sweat
Orifice (057/051) Orifice (062/057) Orifice (071/059) Orifice (078/062)
R-22 / 104.24 R-22/107.77 R-22/141.34 R-22/148.41
10" sides/18" service 10" sides/18" service 10" sides/18" service 10" sides/18" service
167.0 172.0 189.0 207.0
183.0 187.0 205.0 222.0
ARI ARI ARI ARI
UL/cUL UL/cUL UL/cUL UL/cUL
Basiloid Basiloid Basiloid Basiloid
Height 28 1/2 28 1/2 28 1/2 32
Width 26 7/8 26 7/8 26 7/8 26 7/8
Depth 26 7/8 26 7/8 26 7/8 26 7/8
11.92 11.92 11.92 13.38
5555
5555
65 66 68 70
Agency Approvals
Packaging
Warranty(Haier Brand Only)
Dimensions and Installation
Weight (lbs)
Max Vertical
Distance (Ft)
Refrigerant
Line
Service Valves
Refrigerant Connection Type
Unit
Dimensions
(inches)
Liquid Line Dimension (In)
Vapor Line Dimension (In)
Max Refrigerant Line Length (Ft)
Net
Refrigerant Type / Charge (Oz) (
Note 2 )
Compressor
Carton Type
Shipping
Carton
Dimensions
Cubic Volume (Cu. Ft)
Parts
Ship
Performance Certification
Safety Approvals
Metering device (Piston size)Cooling /heating
Min Clearances
Noise level dB(A)
