SERVICE MANUAL
H RF 520 B/F W/HS/HC
Chapter 3 Disassembly and Installation
3-1 Disassembly of refrigerator/freezer air duct, freezer fan, lamps and
other relative components
3-1-1 Disassembly of refrigerator air duct
Refrigerating and freezing volume of
the refrigerator
Refrigerator type
Haier
W: White
H: Non-plumbed Water Dispenser
S: Stainless Steel
C: Black Stainless Steel
B: BM F: French
