DOOR HANDLE INSTALLATION
For refrigerators without a mounting screw
installed on the face of both doors:
Remove both handles from the freezer
compartment and the screws and handle trim
pieces from the parts-included bag.
FREEZER DOOR HANDLE
1. Mount the tapered end of the handle to the
door face using the enclosed screw. Do not
use the screw hole closest to the center of the
handle.
2. Attach the flat end of the handle to the
underside of the door using the enclosed
screws.
3. Insert tab on handle trim cover into slot in
handle and then press firmly onto handle.
REFRIGERATOR DOOR HANDLE
1. Mount the tapered end of the handle to the
door face using the enclosed screw. (Fig. 3) Do
not use the screw hole closest to the center of
the handle.
2. Attach the flat end of the handle to the top of
the door using the enclosed screws. (Fig. 4)
3. Insert tab on handle trim cover into slot in
handle then press firmly onto handle. (Fig. 5)
4. If re-installing handles after reversing the
door swing, remove the screw hole plug from
the parts-included bag and place it in the
handle-mounting screw hole on the face of the
refrigerator door.
5. The name badge can be removed by using a
putty knife or flat head screwdriver to pry the
badge off the door face, being careful not to
damage the finish. Any residue left on the face
of the door from the badge should be removed
by using Goo Gone
©
or WD-40
©
. Be sure to
follow the manufacturer’s instructions when
using these products.
Do not use any abrasives or scouring pads to
remove the residue.
An extra logo badge is provided in the parts-
included bag with your refrigerator. That badge
can be used to cover the handle-mounting screw
hole on the face of the freezer door.
PAGE 9 • SET UP & USE
ENGLISH
DOOR HANDLE INSTALLATION CONT.
Fig. 3
Fig. 4
Fig. 5
