Haier HTF-520IP7 - Product Description

EN
Product description
A: Refrigerator compartment
1 Bottle holder/Door rack
2 Glass shelves
3 Rating plate
4 Wine rack
5 Humidity box
6 Vertical beam
7 Ceiling lamp
8 Air duct and sensor (behind panel)
9 O.K.-temperature indicator (optional)
10 MyZone slider
11 Air duct (behind drawers)
12 MyZone box
B: Freezer compartment
13 Sliding shelf
14 Freeze box
15 Air duct
16 Adjustable feet
17 Auto ice maker (HTF-520IP7)
18 Ice tray (HTF-520IP7)
19 Water dispensing
(HTF-520IP7/ HTF-520WP7)
Notice
Due to technical changes and dierent models, some of the illustrations in this manual
may dier from your model.
11
will be
modied
A
B
13
14
16
5
6
15
18
17
1
7
8
1
9
11
12
2
1
10
3
4
Fruit&Vegetable
Chiller
