Assembly steps
Provide necessary tool.
Unplug the appliance.
1
2
3
4
5
6
6.1
7
7.1
8
9
Installation
EN
18
4. Remove the cable tray cover and trim cover, Left
and right transposition installation of decorative
cover.
5. Remove hinge cover,Use the tool to remove 3
screws and remove the portal body .
6. Remove the 3 screws under the portal body with
the tool,portal body cam and door stop,
the left and right transposition is installed on the
other side of the portal body .
7. Remove the box hinge assembly with the tool,
assembly,replace the hinge shaft to the right
screw hole,assembly.Transposition installation
with the caster support assembly on the right side
of the box.
8. The portal body is installed vertically downward
on the hinge shaft.
9.
the wire box cover and the upper beam trim cover.
3. Remove the upper beam cover and small cover,
Left and right transposition installation of small cover.
