Haier LE32V600 - REAR AV CONNECTIONS; ANTENNA CONNECTION

-6-
REAR AV Connections
All the terminals are (from left to right):
HDMI 1, VGA, Y/VIDEO, Pb, Pr, L, R, VIDEO OUT, AUDIO.
Note: VIDEO and YPbPr share one audio channel.
ANTENNA
Loosen the screws Insert the feeder in Wires
Note:
Aerial connections: IEC (female).
Input impendance: 75Ω unbalanced.
Plug
An outdoor antenna
An outdoor antenna
CATV net
TWIN-LEAD FEEDER(300Ω)
ANT 75Ω
Adaptor (NOT SUPPLIED)
Tighten the screws
INSTALLATION
