SERVICE MANUAL
Model: WS49GDB
12
Issue 2014-12-10
Rev.
FZ1412S025V3
4-3. Heater
a. Firstly, pick out all wine supports. Then remove b. Pick out the middle separate structure
Fan baffle ,loosen the Philip screws on the two
sides of the middle separate structure
c. then open the evaporator from left to right ,the heater on the back of the box,then it
can be changed..
