Haier WS49GDB User Manual

SERVICE MANUAL
Model: WS49GDB
18
Issue 2014-12-10
Rev.
FZ1412S025V3
3.Red Wine Indicator 4. White Wine Indicator
5.Upper Compartment Indicator 6.LED Temperature Display -Upper Compartment
7.Lower Compartment Indicator 8.LED Temperature Display –lower Compartment
9.Temperature Set Button 10.Interion Light Button
1. Adjustable temperature display: While entering the temperature by pressing the temperature
buttons about 3 second ,the set temperature will flash on the display. To reduce the temperature, press
the button ▼;To increase the temperature ,press the top button ▲.
2.The small yellow lamp is the LAMP switch. When the lamp is on, the Interior light will run.
3.The small red lamp is the ALARM lamp .When the lamp is on ,the alarm will be on.
Once you have plugged the unit into an electrical outlet, Let the unit run for at
least 30 minutes to adjust itself before making any adjustments, during this time, depending on the
internal temperature, the red or white wine light will stay
on for the upper compartment and red or white wine light will stay on for the lower.
The wine cellar is present the factory to automatically accommodate temperature requirements for red
or white wines. The wine cellar can be set to any temperature between 6°C and 18 °C in either of
the compartments to accommodate your wine storage requirements. To set the temperature, hold the
“set” button for about 3 seconds. You will notice the temperature display blink for the upper
compartment. Press the up or down arrow button to increase or decrease the temperature
setting ,Once the desired temperature is at tainted, press the “Set” button, Doing this, the electronic
control panel will memorize the setting, The temperature display will revert back to display the inside
temperature, It may take some time to reach the set temperature. Once the temperature is set for the
upper compartment ,you will notice the temperature display blink for the lower compartment. Again
press the up or down arrow button to increase or decrease the temperature, Once the desired
temperature is attained. press the “set” button. Doing this, the electronic
control panel will memorize the setting. The temperature display will revert back to display the inside
temperature. It may take some time reach the set temperature.
Light control:

Haier WS49GDB Specifications

General

Door hinge	Right
Inner color	-
Housing color	Black
Shelves material	Wood
Number of shelves	9 shelves
Appliance placement	Freestanding
Number of compressors	1
Filtering	Yes
Noise level	42 dB
Bottles capacity	49 bottle(s)
Temperature range (zone 1)	- °C
AC input voltage	220-240 V
AC input frequency	50 Hz
Annual energy consumption	190 kWh
Package depth	610 mm
Package width	568 mm
Package height	1340 mm
Package weight	62000 g

Weight and Dimensions

Depth	540 mm
Width	500 mm
Height	1270 mm
Weight	58000 g
