Appearance, Dimension and Interface
1------------ Reset Port
2------------ Signal Ground Wire of Unit B
3------------ Signal Line of Unit B
4------------ Signal Ground Wire of Unit A
5------------ Signal Line of Unit A
6------------ Central Control Interface — B
7------------ Central Control Interface — A
8------------ Communication Line for RS-232 Linking Control Computer or Communication Line
of MODEM (We only offer agreement of deteetor for programming control software )
9------------ Power Cord. If damaged, to avoid dangers, the power cord must be replaced by
manufacturer or its maintenance department or similar professional staff.
Performance Parameters and Accessories
Power Supply 1PH, 220~230VAC, 50Hz
Consumed Power 3W
The Maximum Dimension 139 × 142 × 55 mm
Weight 0.53 kg
Accessories
2 pieces of communication line to air conditioner
(UL2547, AWG24 2C) (Core: red/white)
Chff^j\bZe Abj Chg]blbhg^j
z 51 z
